Dobot CR3S V2 Collaborative Robot

Dobot CR3S V2 Collaborative Robot – 3kg Payload | Short Arm | Compact & Precise Automation

Smart Precision in a Slim, Compact Package

The Dobot CR3S V2 is the updated version of Dobot’s short-reach Cobot, purpose-built for tight work cells and benchtop automation. Engineered for light-duty, repetitive, and accurate tasks, it’s ideal for electronics assembly, lab automation, and training scenarios.

Despite its compact size, the CR3S V2 features advanced AI-driven safety systems, intuitive drag-to-teach programming, and multi-protocol compatibility—making it easy to use, quick to set up, and powerful enough to enhance any compact automation workflow.

Key Features & Benefits:

• 3kg Payload Capacity – Perfect for light tools, parts, and assembly components
• 520mm Short Arm Reach – Built for space-saving automation on desktops or inside machines
• ±0.02mm Repeatability – Exceptional accuracy for precision-driven tasks
• AI-Powered Safety – Includes collision detection, safety zones, and real-time feedback
• Simple Programming Interface – Supports drag-to-teach, graphical UI, and code (Python, C, C++)
•  Industrial Connectivity – Easily integrates with ROS, Modbus, TCP/IP, RS485, and PLCs
• Plug-and-Play Deployment – Minimal setup time and training required

Ideal Applications:

✅ Electronics Handling & Assembly – PCB placement, testing, soldering

✅ Laboratory Automation – Pipetting, transferring, micro-level handling

✅ STEM & Technical Education – Excellent for classroom training and R&D

✅ Compact Pick-and-Place – Fast, accurate part transfer in small spaces

✅ Medical & Testing Equipment Automation

Technical Specifications:

Model: Dobot CR3S V2

Degrees of Freedom: 6

Payload: 3kg

Reach: 520mm

Repeatability: ±0.02mm

Max Joint Speed: 180°/s

Weight: ~16kg

Power Supply: 100–240V AC, 50/60Hz

Communication: Modbus TCP, TCP/IP, RS485, ROS

Software Support: DobotStudio, DobotSCStudio, Python, C, C++

Why Choose the CR3S V2?

✔ Short Reach Design for Confined Workspaces

✔ High-Precision for Light-Duty Automation

✔ Safe and Easy to Operate

✔ Fast Setup with Flexible Programming Options

✔ Ideal for Education, Labs, and Compact Production

What’s Included:

• Dobot CR3S V2 Robotic Arm
• Control Box & Power Adapter
• Communication Cables
• Mounting Accessories
• Software License & Manuals

Get Industrial Precision in a Compact Package – Order the Dobot CR3S V2 Today!
